Ubiquiti UniFi Gateway Pro
The UXG Pro is a powerful, secure gateway with versatile networking and threat management capabilities. It has multiple WAN and LAN ports for failover and high-speed connectivity, and offers advanced security features such as DPI, IDS/IPS, and a layered firewall. Pair with a Cloud Key Plus for easy management through UniFi Network.
Tech Specs
Click here for the UniFi Gateway Pro datasheet.
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2") |
| Max. WAN Port Count | 3 |
| Default WAN Ports | (1) 10G SFP+ (1) GbE RJ45 |
| Port Layout | 10G SFP+ 2 (10G/1G) |
| IDS/IPS Throughput | 3.5 Gbps |
| Form Factor | Rack mount (1U) |
| Redundancy | DC Power Backup |
| Security | |
| Stateful Firewall | โ |
| Application-Aware Layer 7 Firewall | โ |
| DPI & Traffic Identification | โ |
| Zone-Based Firewall Advanced Filtering | Regions, Domains, Apps โ |
| Content Filtering | โ |
| Intrusion Prevention (IPS/IDS) | โ |
| Ad Blocking | โ |
| IDS/IPS Signatures | 55,000+ With CyberSecure |
| VPN & SD-WAN | |
| License-Free SD-WAN | โ |
| Site-to-Site VPN | Site Magic โ |
| IPsec / OpenVPN | โ |
| VPN Server | Teleport Zero-Configuration VPN WireGuard OpenVPN L2TP โ |
| VPN Client | OpenVPN WireGuard โ |
| Networking | |
| Multi-WAN Load Balancing | โ |
| Dynamic Routing | OSPF โ |
| Advanced QoS | โ |
| Multicast DNS (mDNS) | โ |
| Advanced NAT | SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT โ |
| Integrated RADIUS Server | โ |
| RADIUS over TLS (RadSec) | โ |
| Additional Internet Failover | With UniFi LTE Backup โ |
| Internet Quality & Outage Reporting | โ |
| Hardware | |
| Max. Power Consumption | 30W |
| Power Method | US: (1) Universal AC input, 125V AC, 2.7A Max., 60 Hz (1) RPS DC input, 11.5V DC, 2.87A Worldwide: (1) Universal AC input, 200-240V AC, 1.7A Max., 50/60 Hz (1) RPS DC input, 11.5V DC, 2.87A |
| Power Supply | AC/DC, internal, 50W |
| Supported Voltage Range | 100โ240V AC |
| Processor | Quad-core ARMยฎ Cortexยฎ-A53 at 1.5 GHz |
| System Memory | 2 GB |
| Weight | 3.4 kg (7.5 lb) |
| Enclosure Material | Front panel: Aluminum CNC Top cover/base: SGCC steel |
| LCM Display | 1.3" touchscreen |
| Management | Ethernet |
| LEDs | Ethernet โ SFP+ โ RPS โ AC Outlet โ |
| Button | (1) Factory-reset |
| ESD/EMP Protection | Air: ยฑ 15kV Contact: ยฑ 8kV |
| Ambient Operating Temperature | -10 to 40ยฐ C (14 to 104ยฐ F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| NDAA Compliant | โ |
| Certifications | CE, FCC, IC |
| Software | |
| Application Requirements | UniFi Network Version 8.3.32 and later |
ย
FAQs
Q. What type of device is the Ubiquiti UXG-Pro?
A: The UXG-Pro is a high-performance UniFi Next-Gen Gateway that delivers enterprise-class routing, dual WAN failover, and advanced firewall protection.
Q. What performance capabilities does the UXG-Pro provide?
A: The UXG-Pro supports multi-gigabit throughput with 10G SFP+ interfaces and offers advanced security features like IDS/IPS and deep packet inspection.
Q. How does the UXG-Pro integrate with UniFi Network?
A: It is centrally managed via the UniFi Network application, enabling easy configuration, real-time monitoring, and seamless integration with UniFi devices.
Q. What networking and power options are available for the UXG-Pro?
A: The device includes dual WAN ports (1x 10G SFP+ and 1x Gigabit RJ45), multiple LAN ports, and dual power options with a built-in PSU and RPS (Redundant Power System) support.
Q. What installation environments are ideal for the UXG-Pro?
A: The UXG-Pro is suited for enterprise networks, ISPs, and advanced prosumer environments needing high-speed routing, redundancy, and robust security.
