Ubiquiti UniFi Pro 24 Port Switch
Ubiquiti UniFi Pro 24 – Silent 24-Port Layer 3 Switch with 10G SFP+ Uplinks
The UniFi Pro 24 is a high-performance Layer 3 switch designed to deliver reliable gigabit connectivity with advanced routing features. It includes 24 GbE ports and two 10G SFP+ uplinks, making it ideal for linking UniFi access switches, servers, or high-speed backhaul connections.
Supporting Layer 3 switching, the Pro 24 enables advanced network segmentation and routing, enhancing efficiency in larger UniFi deployments. It is also DC power backup-ready, ensuring resilience and uptime in critical network environments.
With fanless cooling for silent operation, the UniFi Pro 24 is well-suited for offices, retail environments, classrooms, and other professional deployments where both performance and quiet operation are essential. Fully managed via the UniFi Network application, it provides centralised control, monitoring, and seamless integration into wider UniFi infrastructures.
Any EU products are supplied with the appropriate UK power method at no extra cost.
Tech Specs
Click here for the UniFi USW-Pro-24 datasheet.
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | 442 x 285 x 44 mm (17.4 x 11.2 x 1.7") |
| Port Layout | 1 GbE RJ45: 24 (1G/100M/10M) 10G SFP+: 2 (10G/1G) |
| Redundancy | DC Power Backup |
| Layer 3 | ✓ |
| Form Factor | Rack mount (1U) |
| Performance | |
| Switching Capacity | 88 Gbps |
| Total Non-Blocking Throughput | 44 Gbps |
| Forwarding Rate | 65 Mpps |
| Supported VLANs | 1,000 |
| MAC Address Table Size | 16,000 |
| L3 Table Size | ARP Entries: 768 IPv4 Routes: 64 |
| Packet Buffer Size | 2 MB |
| Access Lists | IPv4: 128 MAC: 128 |
| Layer 3 Features | |
| DHCP Server (Local Networks) | ✓ |
| DHCP Relay | ✓ |
| Inter-VLAN Routing (Local Networks) | ✓ |
| Static Routing (Local Networks) | ✓ |
| Layer 2 Features | |
| Features | LACP Port Aggregation ✓ STP & RSTP ✓ QoS (DSCP) ✓ Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron) ✓ Advanced IGMP Configuration (Querier, Fast Leave, Router Port) ✓ IGMP Snooping ✓ 802.1X Control ✓ MAC-Based ACLs & Device Isolation ✓ DHCP Snooping & Guarding ✓ Egress Rate Limit ✓ Flow Control ✓ Storm Control ✓ Multicast & Broadcast Rate Limiting ✓ MAC Address Blocking ✓ IP-Based ACLs & Network Isolation ✓ MAC-Based Port Restriction ✓ Port Isolation ✓ Port Mirroring ✓ Jumbo Frames ✓ LLDP-MED ✓ Voice VLAN ✓ Loop Protection ✓ |
| Hardware | |
| Max. Power Consumption | 30W |
| Power Method | (1) Universal input, 100—240V AC, 50/60 Hz (1) USP RPS DC input |
| Power Input Method | AC input |
| Power Supply | AC/DC, internal, 36W |
| Supported Voltage Range | 100—240V AC |
| Management | Ethernet AR |
| Heat Dissipation | 102.36 BTU/hr (Excluding PoE Output) |
| Weight | Without mounting brackets: 3.5 kg (7.7 lb) With mounting brackets: 3.6 kg (7.9 lb) |
| Enclosure Material | SGCC steel |
| Mount Material | SGCC steel |
| Supported Rack Depth | 400~1200 mm (15.7-47.2") |
| LCM Display | 1.3" touchscreen |
| ESD Protection | Air: ±16kV, contact: ±12kV |
| Ambient Operating Temperature | -5 to 45° C (23 to 113° F) |
| Ambient Operating Humidity | 10 to 90% noncondensing |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC, Anatel |
| Software | |
| Application Requirements | UniFi Network Version 5.12.11 and later |
FAQs
Q: What is the Ubiquiti USW-Pro-24 and what is its primary function?
A: The USW-Pro-24 is a fully managed Layer 3 UniFi rack-mount switch featuring 24 Gigabit RJ45 ports and two 10 GbE SFP+ uplinks. It’s designed for high-bandwidth, silent switching in professional network environments.
Q: What performance capabilities does the USW-Pro-24 offer?
A: It delivers 88 Gbps switching capacity, 44 Gbps non-blocking throughput, and a forwarding rate of 65 Mpps
Q: What advanced Layer 2 and Layer 3 features are supported?
A: The switch supports inter-VLAN routing, static routing, DHCP server/relay, VLANs, LACP, STP/RSTP, QoS, ACLs, IGMP snooping, VLAN isolation, jumbo frames, and more—all manageable via the UniFi Network Application.
Q: What design features enhance its usability?
A: It features a fanless, near-silent design, an integrated 1.3″ touchscreen for local status and diagnostics, and support for the UniFi SmartPower RPS for power redundancy.
Q: What are the physical specs and environmental tolerances of the switch?
A: It measures 442 x 285 x 44 mm (1U rack), weighs approximately 3.5 kg (7.7 lb), supports 100–240 VAC power with optional RPS backup, operates between –5 °C to 45 °C, and includes ESD protection and NDAA compliance.
Resources
Guide: UniFi Network for Retail and Hospitality — MS Dist
Guide: Setting Up a Ubiquiti UniFi Network for a Small Office or Business — MS Dist
