Ubiquiti airMAX Lite AP
This Ubiquiti airMAX Lite AP boasts an ultra-lightweight design and a versatile, ball-join mount. Its key features include an integrated 5 GHz antenna, a remarkable 10+ km link range, impressive 450+ Mbps throughput, and a high client capacity of 50+. It also comes equipped with a dedicated spectral analysis radio for enhanced performance.
Any EU products are supplied with the appropriate UK power method at no extra cost.
Tech Specs
Click here for the Ubiquiti airMAX Lite AP datasheet.
| Device Specifications | |
|---|---|
| Mechanical | |
| Dimensions | 452.3 x 78.7 x 54.4 mm (17.8 x 3.1 x 2.14") |
| Weight | 420 g (14.82 oz) |
| Wind survivability | 200 km/h (125 mph) |
| Wind loading | 77 N at 200 km/h (17.3 lbf at 125 mph) |
| Hardware | |
| Networking interface | (1) GbE RJ45 port |
| Power method | Passive PoE 2-pair (4, 5+; 7, 8 return) |
| Power supply | 24V, 0.5A gigabit PoE adapter (Included) |
| Supported voltage range | 20–27V DC |
| Max. power consumption | 8W |
| Antenna gain | 16 dBi |
| ESD/EMP protection | Air/contact ± 24kV |
| Shock and vibrations | ETSI300-019-1.4 |
| Ambient operating temperature | -40 to 70° C (-40 to 158° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Operating Frequency (MHz) | |
| US/CA | U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz |
| Worldwide | 5150 - 5875 MHz |
| NDAA Compliant | Yes |
Â
FAQs
Q1: What is the Ubiquiti LAP-120?
A1: The LAP-120 is a 5 GHz airMAX ac sector access point designed for outdoor wireless broadband applications. It features a 16 dBi integrated antenna and supports both point-to-multipoint (PtMP) and point-to-point (PtP) configurations.
Q2: What are the key specifications of the LAP-120?
A2:
-
Dimensions: 452.3 x 78.7 x 54.4 mm (17.8 x 3.1 x 2.14")
-
Weight: 420 g (14.82 oz)
-
Antenna Gain: 16 dBi
-
Frequency Band: 5 GHz (Worldwide: 5150–5875 MHz)
-
Networking Interface: (1) Gigabit Ethernet RJ45 port
-
Power Method: Passive PoE (Pairs 4, 5+; 7, 8 return)
-
Power Supply: 24V, 0.5A Gigabit PoE adapter (Included)
-
Max Power Consumption: 8W
-
Operating Temperature: -40°C to 70°C (-40°F to 158°F)
-
Certifications: CE, FCC, IC
Q3: What throughput and range can the LAP-120 achieve?
A3: The LAP-120 can deliver up to 450 Mbps real TCP/IP throughput. In optimal conditions, it supports link distances exceeding 10 km.
Q4: How is the LAP-120 powered and installed?
A4: The LAP-120 is powered via 24V passive PoE and includes a pole-mounting kit for easy installation. Its lightweight design and integrated antenna simplify alignment and setup.
Q5: What software features does the LAP-120 support?
A5: The LAP-120 supports Ubiquiti’s airMAX ac protocol, which utilizes Time Division Multiple Access (TDMA) to reduce latency and improve scalability. It also features a dedicated spectral analysis radio for interference mitigation.
