Ubiquiti UISP Switch Pro
The Ubiquiti UISP Switch Pro has a total PoE availability of 220W (27V) and features (24) GbE RJ45 ports with (16) supporting 27V passive PoE, as well as (4) 10G SFP+ ports. The switch also offers port isolation, speed limiting, and DHCP snooping functionality, along with a 1.3" LCM color touchscreen. An additional Power TransPort input is included for DC redundancy.
Any EU products are supplied with the appropriate UK power method at no extra cost.
Tech Specs
Click here for the Ubiquiti UISP Switch Pro datasheet.
| Device Specifications | |
|---|---|
| Physical | |
| Dimensions | 442.4 x 267.5 x 43.7 mm (17.4 x 10.5 x 1.7") |
| Weight | 4 kg (8.8 lb) |
| Enclosure materials | SGCC steel, polycarbonate/acrylonitrile butadiene styrene |
| Hardware | |
| Networking interface | (24) GbE RJ45 LAN ports (4) 1/10G SFP+ ports |
| Management interface | Ethernet In-band Bluetooth |
| Total non-blocking throughput | 64 Gbps |
| Switching capacity | 128 Gbps |
| Forwarding rate | 95.23 Mpps |
| Power | |
| Power method | (1) Universal AC input, 100-240V AC, 4.4A Max., 50/60 Hz (1) Power TransPort DC input 27V DC, 9.3A |
| Power supply | AC/DC, Internal, 250W |
| Supported voltage range | 100–240V AC |
| Max. power consumption | 30W (Excluding PoE output) |
| ESD/EMP protection | Air: ± 15 kV Contact: ± 8 kV |
| Display | |
| LCM display | (1) 1.3" touchscreen |
| Environment & Compliance | |
| Ambient operating temperature | -10 to 50° C (14 to 122° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| PoE | |
| PoE interface | (16) 27V passive PoE: 2-pair (Pins 4, 5+/7, 8-) or 4-pair (Pins 1, 2, 4, 5+/3, 6, 7, 8-); Ports 1 to 16 |
| Total available PoE | 220W |
| Max. passive PoE wattage per port | 30W / 27V DC |
| Passive PoE voltage range | 27V DC |
| LEDs | |
| RJ45 data ports | PoE, Speed/link/activity |
| SFP+ data ports | Speed/link/activity |
| Software | |
| Management application | UISP: Version 1.5.7 and later |
| NDAA Compliant | Yes |
Â
FAQs
Q1: What is the UISP‑S‑Pro used for?
A: The UISP‑S‑Pro is a managed network switch designed for business or high-demand network environments. It provides many Gigabit ports plus high‑speed uplinks and strong PoE support, suitable for powering devices like access points, cameras, or other PoE‑enabled equipment while handling data traffic across a network.
Q2: How many and what types of ports does the UISP‑S‑Pro have?
A: It offers 24 Gigabit RJ45 Ethernet ports (LAN), of which 16 support passive 27 V PoE, plus 4 SFP+ ports capable of 1 Gb or 10 Gb fiber/copper uplinks.
Q3: What PoE power capacity does the switch support?
A: The switch supplies up to 220 W total PoE budget. PoE output per port can go up to 30 W (with 4‑pair mode) or 15 W (with 2‑pair mode), enabling it to power multiple medium-to-high power PoE devices simultaneously.
Q4: What are the performance and throughput specifications?
A: The switch has a non‑blocking throughput of 64 Gbps, a total switching capacity of 128 Gbps, and a forwarding rate of approximately 95.23 Mpps, enabling high-performance switching for heavy traffic or multiple simultaneous streams.
Q5: What are the physical, power, and building‑management features?
A: The switch is rack‑mountable (1U 19"), with dimensions ~442.4 × 267.5 × 43.7 mm and a weight of ~4 kg. It includes an internal 250 W AC/DC power supply, accepts 100–240 V AC input, and also supports DC‑input redundancy. A built‑in 1.3" touchscreen helps with on‑device status and management.
