Ubiquiti UniFi U6 Enterprise In-Wall
Discover the Ubiquiti U6 Enterprise In-Wall, a high-performance tri-band Access Point perfect for crowded office networks. With its stylish wall-mounted design and compatibility with WiFi 6, it seamlessly connects across 2.4/5/6 GHz bands. Supporting over 200 clients at once, this access point offers a 1.733 Gbps throughput rate on the 5 GHz band and 300 Mbps on the 2.4 GHz band. Featuring PoE power and 5 GbE RJ45 ports, including a configurable PoE passthrough port, the Ubiquiti U6 is essential for modern offices.
Tech Specs
Click here for the UniFi U6 Enterprise In-Wall datasheet.
| Device Specifications | |
|---|---|
| Overview | |
| Dimensions | 159.7 x 156.7 x 33.8 mm (6.3 x 6.2 x 1.3") |
| WiFi Standard | WiFi 6E |
| Spatial Streams | 10 |
| Coverage Area | 115 m² (1,250 ft²) |
| Max. Client Count | 600+ |
| Uplink | 2.5 GbE |
| Mounting | Wall (Mount Included) |
| Power Method | PoE+ PoE++ (Required for PoE output) |
| Performance | |
| MIMO | 6 GHz: 4 x 4 (DL/UL MU-MIMO) 5 GHz: 4 x 4 (DL/UL MU-MIMO) 2.4 GHz: 2 x 2 (DL/UL MU-MIMO) |
| Max. Data Rate | 6 GHz: 4.8 Gbps (BW160) 5 GHz: 4.8 Gbps (BW160) 2.4 GHz: 573.5 Mbps (BW40) |
| Antenna Gain | 6 GHz: 5.8 dBi 5 GHz: 5.8 dBi 2.4 GHz: 4 dBi |
| Max. TX Power | 6 GHz: 26 dBm 5 GHz: 26 dBm 2.4 GHz: 22 dBm |
| Max. BSSIDs | 8 per Radio |
| Supported Data Rates | 802.11ax (WiFi 6/6E): 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160) 802.11ac (WiFi 5): 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160) 802.11n: 6.5 Mbps to 600 Mbps (MCS0 - MCS31 , HT 20/40) |
| Features | |
| Wireless Features | Wireless Meshing ✓ Band Steering ✓ 802.11v BSS Transition Management ✓ 802.11r Fast Roaming ✓ 802.11k Radio Resource Management (RRM) ✓ Advanced Radio Management ✓ |
| Hotspot & Authentication | Passpoint (Hotspot 2.0) ✓ Custom Branding Landing Page ✓ Voucher Authentication ✓ Payment-Based Authentication ✓ External Portal Server Support ✓ Password Authentication ✓ Guest Network Isolation ✓ Private Pre-Shared Key (PPSK) ✓ |
| Management & Security | WiFi Speed Limiting ✓ Client Device Isolation ✓ WiFi Schedules ✓ RADIUS over TLS (RadSec) ✓ Dynamic RADIUS-assigned VLAN ✓ |
| Hardware | |
| Max. Power Consumption | 21W (Excluding PoE output) |
| Supported Voltage Range | 44—57V DC |
| Networking Interface | (1) Data in: 1/2.5 GbE RJ45 port (4) Data out: GbE RJ45 ports |
| Weight | 884 g (1.9 lb) |
| Management | Ethernet Bluetooth |
| Built-In Switch | (4) GbE ports with (1) PoE output |
| Enclosure Material | Polycarbonate, aluminum |
| Mount Material | Aluminum |
| LEDs | System White/Blue |
| Channel Bandwidth | HT 20/40, VHT 20/40/80/160, HE 20/40/80/160 (MHz) |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC, Anatel |
| Operating Frequency | US/CA: 2400 - 2472 MHz U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz U-NII-5 to U-NII-8 : 5925 - 7125 MHz Worldwide: 2400 - 2483.5 MHz 5150 - 5725 MHz 5925 - 7125 MHz |
| Ambient Operating Temperature | -30 to 60° C (-22 to 140° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Software | |
| Application Requirements | UniFi Network Version 6.0.45 and later |
FAQs
Q: What is the Ubiquiti U6-Enterprise-IW and what makes it different?
A: The U6-Enterprise-IW is a wall-mounted WiFi 6E access point that supports tri-band wireless, including the 6 GHz spectrum, delivering high-speed coverage in enterprise and hospitality environments.
Q: What frequency bands and WiFi standards does the U6-Enterprise-IW support?
A: It supports WiFi 6E on 2.4 GHz, 5 GHz, and 6 GHz bands with 4×4 MU-MIMO, OFDMA, and advanced beamforming for higher throughput and reduced latency.
Q: How is the U6-Enterprise-IW powered and connected?
A: The device includes a 2.5 GbE RJ45 uplink port with 802.3at PoE+ support, plus multiple GbE downlink ports for wired device connectivity.
Q: Is the U6-Enterprise-IW suitable for in-room or hospitality deployments?
A: Yes, its in-wall design allows discreet installation while providing both high-performance WiFi and wired connectivity for devices like VoIP phones, smart TVs, or desktops.
Q: How is the U6-Enterprise-IW managed?
A: It integrates with the UniFi Network Application, enabling centralised configuration, monitoring, and performance optimisation across multiple enterprise APs.
Resources
Guide: UniFi Network for Retail and Hospitality — MS Dist
Guide: Setting Up a Ubiquiti UniFi Network for a Small Office or Business — MS Dist
